4KW Hybrid Inverter 24V with built in MPPT 500V CE-H4K

300,000 CFA

  • 4000W Continuous Output: Unlike many mid-range inverters that struggle with surges, this unit provides a full 4kW of clean Pure Sine Wave power. This is sufficient for multiple fans, a large refrigerator, lighting, and a home entertainment system simultaneously.

  • High-Voltage PV Input (500V): The ability to handle up to 500V Voc is a premium feature for a 24V inverter. It allows you to wire panels in series, which simplifies installation, reduces the need for heavy-gauge solar cables, and improves performance in low-light conditions.

  • 8000W Surge power limit for 5 seconds
Warranty

This Warranty Assurance Coverage Covers logistics and immediate replacement during the warranty period.

Free installation orders over 1,00000 CFA!

  • Check Mark Satisfaction Guaranteed
  • Check Mark Professional Installation
  • Check Mark Manufacturer Warranty
GUARANTEED SAFE CHECKOUT
  • PayPal

Description

SPECIFICATION:

Inverter Model CE-H1.8K CE-H4K CE-H6K
Rated Output Power(W) 1500W 4000W 6000W
Nominal DC Input Voltage 12V 24V 48V
Nominal Output Voltage 230Vac+5
AC Input Normal Voltage 90-280V
Nominal Output Frequency(Hz) 50±0.2Hz/60±0.2Hz(Adjustable)
Peak  Efficiency 95% 93% 93%
DC Max Charging/Discharge Current(BAT) 105A/150A 120A/160A 120A/125A
Max. PV Open Circuit Voltage 130V 500V 500V
MPPT Operating Voltage Range 15~120V 85~450V 85~450V
Max. Input Current(PV) 20A 15A 27A
Transfer Time (Single unit) 10ms typical (UPS); 20ms typical (Appliances)
Safety Cerification CE
Operating Temperature Range -10°C~50°C
Storage Temperature -15°C~60°C
Net Weight 5.5kg 9.2kg 13kg
Gross Weight 6.5kg 11.4kg 15kg
Product Dimension 350×290×108mm 120×345×443mm 120×345×443mm
Package Dimension 495×385×165mm 240×365×463mm 240×365×463mm
Cworth Energy CE-H4K Hybrid Solar Inverter (4kW/24V)

The Cworth Energy CE-H4K is a high-performance 4000W hybrid inverter that operates on a 24V DC battery system.


Core Features & Benefits
  • 4000W Continuous Output: Unlike many mid-range inverters that struggle with surges, this unit provides a full 4kW of clean Pure Sine Wave power. This is sufficient for multiple fans, a large refrigerator, lighting, and a home entertainment system simultaneously.

  • High-Voltage PV Input (500V): The ability to handle up to 500V Voc is a premium feature for a 24V inverter. It allows you to wire panels in series, which simplifies installation, reduces the need for heavy-gauge solar cables, and improves performance in low-light conditions.

  • 120A MPPT Charge Controller: The built-in controller is exceptionally powerful for a 24V unit, allowing you to charge your battery bank very quickly during peak sunlight hours.

  • Battery-Independent Operation: The CE-H4K is capable of powering your loads directly from solar panels even if a battery is not connected (or is disconnected for maintenance), provided there is sufficient sunlight.

  • BMS Communication: It features an RS485/CAN port specifically designed to communicate with Lithium (LiFePO4) batteries, ensuring the inverter and battery stay synchronized for a longer lifespan..


Best Use Case: “The Modern 3-Bedroom Apartment”

This inverter is ideally suited for urban residents looking for reliable backup:

  • Ideal Pairing: Pairs perfectly with a 24V 200Ah Lithium battery (or two 200Ah Gel batteries in series) and four to six 420W panels.

  • What it Runs: It can comfortably power a large fridge-freezer, a microwave (short bursts), a washing machine (cold cycle), and all standard household electronics.

  • Installation Tip: Since it is a high-frequency inverter, it is best kept in a well-ventilated area. Use 35mm² battery cables to handle the high current flow from the 24V batteries.
