80A MPPT Charge Controller CE-M8048

145,000 CFA

CE-M8048 is a professional-grade, high-capacity MPPT (Maximum Power Point Tracking) charge controller designed to handle large solar arrays. It is an essential component for high-performance off-grid systems, capable of converting high-voltage solar energy into the correct charging voltage for 12V, 24V, or 48V battery banks with up to 98% efficiency. max input 200V

Warranty

This Warranty Assurance Coverage Covers logistics and immediate replacement during the warranty period.

Free installation orders over 1,00000 CFA!

  • Check Mark Satisfaction Guaranteed
  • Check Mark Professional Installation
  • Check Mark Manufacturer Warranty
GUARANTEED SAFE CHECKOUT
  • PayPal

Description

SPECIFICATION:

 Model CE-M8048 CE-M12048
Maximum Battery Current 80A 120A
Battery Type Use-Defined/AGM/FLD/LIB
System Voltage 12V/24V/48V DC(Auto detection)
PV Start-up Voltage 25
Maximum Solar input Voltage 200V
PV Array MPPT Voltage Range
25/30/60V-180VDC(For 12V/24V/48V-system)
Maximum Solar panel input Power 12V-1130W 12V-1700W
24V-2260W 24V-3400W
48V-4520W 48V-6800W
Charging Algorithm 3-Step
Charging stages Bulk, Absorption, Float
Operation Temperature Range -25°C-60°C
Humidity 0%-90%
Maximum Efficiency >98%
Net Weight 4.2kg 6.8kg
Product Dimension 280x178x122mm 340x215x125mm
Cworth Energy CE-M8048 MPPT Solar Charge Controller (80A)

The Cworth Energy CE-M8048 is a professional-grade, high-capacity MPPT (Maximum Power Point Tracking) charge controller designed to handle large solar arrays. It is an essential component for high-performance off-grid systems, capable of converting high-voltage solar energy into the correct charging voltage for 12V, 24V, or 48V battery banks with up to 98% efficiency. max input 200V


Core Features & Benefits
  • Intelligent MPPT Tracking: Increases energy harvest by 25%–30% compared to standard PWM controllers by constantly tracking the “sweet spot” of your panels as the sun moves or clouds pass.

  • High Voltage Input (200V): This allows you to connect 3 or 4 large panels (like the 420W or 550W models) in series. Higher voltage strings mean less energy is lost in the cables and you can use thinner, more affordable wiring.

  • Automatic System Detection: The controller automatically recognizes if you have connected a 12V, 24V, or 48V battery bank. (Note: For Lithium batteries, manual voltage calibration is recommended for precision).

  • Advanced Protection Suite: Includes built-in safeguards against:

    • PV Reverse Polarity

    • Battery Overcharge & Over-discharge

    • Output Short Circuit

    • Internal Over-temperature (Automatic power reduction when hot)

  • Heat Management: Built with a heavy-duty internal heat sink and active cooling fans that adjust speed based on temperature, ensuring it remains cool even during the peak dry season.

  • LCD Display: Provides real-time monitoring of PV voltage, charging current, battery capacity, and any system faults.


Best Use Case: “The 48V High-Yield System”

This controller is a powerhouse for large residential setups:

  • System Pairing: Perfectly suited for an array of eight 550W panels (4,400W total) charging a 48V Lithium or Gel bank.

  • Installation Tip: Use 25mm² battery cables for the connection between the controller and the battery to handle the full 80A current without melting wires or losing energy.

  • Compatibility: Ideal for use with Cworth Energy’s LiFePO4 LBT-series batteries for a fully integrated smart charging experience.

Important Disclaimer & Terms of Purchase

Thank you for visiting tamsolec.com. To ensure transparency and provide you with the best service, please read the following terms and conditions regarding our product listings, pricing, and availability.


1. Product Availability

  • Stock Status: Not all products listed on this website are currently held in our immediate physical stock.

  • Regional Availability: Certain items may only be available through specific partner suppliers located in Douala and/or Yaoundé.

  • Rare Items & Pre-orders: Rare or highly specialized components may only be available via pre-order from China.

  • Verification Required: Before making any purchase, buyers must discuss with us to confirm if the product is in stock or to determine the lead time required to make it available.

2. Pricing Policy

  • Price Ranges: Prices on our site are displayed as a range. The Discount Price (current price) represents the minimum estimated cost, while the Regular Price (stroked price) represents the maximum expected cost for that item.

  • Price Fluctuations: Prices are not guaranteed to remain constant. They are subject to frequent changes due to variations in importation costs, customs duties, and price adjustments from our diverse network of suppliers.

3. Product Descriptions & Expertise

  • Authorship: All product descriptions on this website were professionally crafted by Engr. NJIO CYRIN TAMFU.

  • Sources: Information is compiled using official product/brand datasheets, direct communications from manufacturers, and technical research assisted by Google Gemini to ensure depth and accuracy.

4. Third-Party Coordination & Compatibility

  • Partner Network: For products not in our immediate stock, we act as a third-party coordinator. We work with our trusted partner suppliers to facilitate your purchase.

  • Our Goal: Our role in this coordination is to ensure the buyer receives fair pricing and to verify that the products strictly meet the technical requirements and compatibility of the intended system.


Contact Information

For availability checks, technical consultations, or order inquiries, please contact us directly:

Tamsolec Warranty Assurance & Logistics Policy

At Tamsolec, we understand that a manufacturer's warranty is only as good as the support behind it. Because we operate as a bridge between international manufacturers and the local Cameroonian market, we offer an Optional Warranty Assurance Plan to give our clients total peace of mind.


1. The 5% Warranty Assurance Fee

We offer an optional Warranty Assurance Coverage at a flat rate of 5% of the total product cost.

By opting for this coverage, you are not just buying a product; you are securing a guarantee of service. This small investment ensures that Tamsolec takes full responsibility for the "logistics of replacement."

2. What This Policy Covers

When you pay the 5% Assurance Fee, Tamsolec commits to the following during the item's official warranty period:

  • Active Advocacy: We act as your legal and technical representative to the manufacturer (e.g., Felicity Solar) to ensure your warranty claim is prioritized and approved.

  • Logistics Management: We handle the complex process of returning a defective unit to the regional supplier (Douala/Yaoundé) or the manufacturer and securing the replacement.

  • Direct Replacement: Where possible and subject to availability, we aim to provide a replacement unit from our partner network to minimize your system's downtime.

  • Zero Hidden Fees: For covered claims, the 5% fee covers the administrative and local transport costs associated with the swap.

3. Why This Is Necessary

Standard manufacturer warranties often cover the parts, but they rarely cover the cost of logistics, transport, or the labor required to facilitate a swap between cities or countries.

Without this optional coverage, the buyer is responsible for transporting the damaged item to the authorized service center and following up on the weeks-long (or months-long) administrative process.

4. Terms & Exclusions

  • Original Condition: The warranty (and this assurance) only applies to items that have failed due to manufacturing defects under normal use.

  • Standard Exclusions: Damage caused by lightning (if no SPD was installed), physical impact, water submersion (for non-IP65 items), or unauthorized repair attempts by third-party technicians will void the warranty.

  • Non-Refundable: The 5% fee is a service charge for the duration of the warranty period and is non-refundable once the product has been commissioned.


Secure Your Investment

To add this coverage to your purchase, please inform us during the discussion phase. We highly recommend this for high-value items like Lithium Batteries and Hybrid Inverters.

Contact for Warranty Claims:


CERTIFICATE OF WARRANTY ASSURANCE

Certificate No: TMSL-2025-XXXX

Issue Date: [DD/MM/YYYY]

This document certifies that the products listed below are covered under the Tamsolec Warranty Assurance Plan. By paying the optional 5% Assurance Fee, the Holder is entitled to full logistics support and guaranteed warranty follow-up as managed by Tamsolec.

1. CUSTOMER & SYSTEM DETAILS

  • Customer Name: ________________________________________________

  • Installation Address: __________________________________________

  • Contact Number: _______________________________________________

2. COVERED EQUIPMENT

3. ASSURANCE BENEFITS

By holding this certificate, the buyer is exempted from the technical and logistical burdens of warranty claims. Tamsolec guarantees:

  • Logistics & Transport: We cover the cost and effort of moving damaged units to and from regional service centers (Douala/Yaoundé).

  • Technical Advocacy: Immediate processing of claims with the manufacturer to ensure the fastest possible replacement or repair.

  • System Continuity: Priority access to temporary replacement units (subject to availability) to minimize power downtime.

4. TERMS & CONDITIONS

  • Coverage Activation: This certificate is only valid if the 5% Assurance Fee has been paid in full at the time of purchase.

  • Standard Exclusions: Coverage does not apply to damage caused by:

    1. Lightning strikes (where appropriate Surge Protection Devices were not installed).

    2. Physical abuse, water damage (non-IP65 units), or unauthorized tampering.

    3. Installation by non-certified technicians.

  • Claim Procedure: To initiate a claim, contact the technical desk at +237 654 388 730 with your Certificate Number.


AUTHORIZED SIGNATORY

Engr. NJIO CYRIN TAMFU Technical Director, Tamsolec info@tamsolec.com |
